Komatsu SAA6D114E-2:
Engine model: SAA6D114E-2
Engine type: Water-cooled, 4-cycle, direct injection turbocharged diesel engine
Number of cylinders: 6
Displacement: 8.85 L
Bore x stroke: 114 x 144 mm
Compression ratio: 17.0 : 1
Max. power output: 184 kW (246 HP) at 1950 RPM
Max. torque output: 1238 Nm at 1400 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: Common rail fuel injection system
Cooling system: Water-cooled with gear-driven centrifugal pump and thermostatically controlled fan
Lubrication system: Gear-driven pump with full-flow filter and bypass filter
Emissions compliance: EPA Tier 2/EU Stage II
Weight: Approximately 1,020 kg
Cummins QSC8.3 and 6C8.3:
Engine model: QSC8.3 and 6C8.3
Engine type: Water-cooled, 4-cycle, direct injection turbocharged diesel engine
Number of cylinders: 6
Displacement: 8.3 L
Bore x stroke: 114 x 135 mm
Compression ratio: 17.3 : 1
Max. power output: 184 kW (246 HP) at 2200 RPM
Max. torque output: 1150 Nm at 1500 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: High-pressure common rail fuel injection system
Cooling system: Water-cooled with gear-driven centrifugal pump and thermostatically controlled fan
Lubrication system: Gear-driven pump with full-flow filter and bypass filter
Emissions compliance: EPA Tier 3/EU Stage IIIA
Weight: Approximately 850 kg
