Caterpillar 3306 engine:
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 10.5 liters (638 cubic inches)
Bore and stroke: 121 mm x 152 mm (4.75 in x 6.00 in)
Compression ratio: 16.5:1
Max power output: 224 kW (300 hp) at 2,200 RPM
Max torque: 1215 Nm (895 lb-ft) at 1,400 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: Direct injection
Cooling system: Water-cooled with heat exchanger
Lubrication system: Forced lubrication with gear-driven pump
Caterpillar 3306TA engine:
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 10.5 liters (638 cubic inches)
Bore and stroke: 121 mm x 152 mm (4.75 in x 6.00 in)
Compression ratio: 16.5:1
Max power output: 261 kW (350 hp) at 2,200 RPM
Max torque: 1356 Nm (1000 lb-ft) at 1,400 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: Direct injection
Cooling system: Water-cooled with heat exchanger
Lubrication system: Forced lubrication with gear-driven pump
Caterpillar D7G engine:
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 14.6 liters (892 cubic inches)
Bore and stroke: 121 mm x 165 mm (4.75 in x 6.5 in)
Compression ratio: 17.5:1
Max power output: 149 kW (200 hp) at 2,100 RPM
Max torque: 895 Nm (660 lb-ft) at 1,400 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: Direct injection
Cooling system: Water-cooled with heat exchanger
Lubrication system: Forced lubrication with gear-driven pump
Caterpillar D6D engine:
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 10.5 liters (638 cubic inches)
Bore and stroke: 121 mm x 152 mm (4.75 in x 6.00 in)
Compression ratio: 16.5:1
Max power output: 128 kW (172 hp) at 2,000 RPM
Max torque: 753 Nm (556 lb-ft) at 1,400 RPM
Aspiration: Turbocharged and aftercooled
Fuel system: Direct injection
Cooling system: Water-cooled with heat exchanger
Lubrication system: Forced lubrication with gear-driven pump
Caterpillar 330B engine:
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 10.5 liters (638 cubic inches)
Bore and stroke: 121 mm x 152 mm (4.75 in x 6.00 in)
Compression ratio: 16.5:1
Max power output: 180 kW (241 hp) at 2,000 RPM
Max torque: 1056 Nm (779 lb-ft)
