SAA6D170E-3: This is a diesel engine manufactured by Komatsu, which is commonly used in large mining and construction equipment. Here are some specifications for this engine:
Displacement: 23.15 liters
Number of cylinders: 6
Bore x stroke: 170 mm x 170 mm
Compression ratio: 15.0:1
Max power output: 1030 kW (1380 hp) @ 1800 rpm
Max torque: 6240 Nm (4600 lb-ft) @ 1100 rpm
Emissions level: Tier 3/Stage IIIA
6D107-3: This is a diesel engine manufactured by Komatsu, which is commonly used in construction equipment such as excavators and bulldozers. Here are some specifications for this engine:
Displacement: 4.5 liters
Number of cylinders: 4
Bore x stroke: 107 mm x 124 mm
Compression ratio: 17.2:1
Max power output: 123 kW (165 hp) @ 2200 rpm
Max torque: 677 Nm (500 lb-ft) @ 1600 rpm
Emissions level: Tier 3/Stage IIIA
QSK23-C: This is a diesel engine manufactured by Cummins, which is commonly used in power generation, mining, and marine applications. Here are some specifications for this engine:
Displacement: 23 liters
Number of cylinders: 6
Bore x stroke: 170 mm x 200 mm
Compression ratio: 15.0:1
Max power output: 783 kW (1050 hp) @ 1800 rpm
Max torque: 4775 Nm (3520 lb-ft) @ 1500 rpm
Emissions level: Tier 1/Stage I
EX1200: This is an excavator manufactured by Hitachi, which is commonly used in mining and construction applications. Here are some specifications for this excavator:
Operating weight: 235,000 lbs (106,594 kg)
Engine: Cummins QSK23-C
Max digging depth: 26'3" (8.0 m)
Max digging reach: 44'7" (13.6 m)
Max dumping height: 33'10" (10.3 m)
PC1250SP-8: This is an excavator manufactured by Komatsu, which is commonly used in mining and construction applications. Here are some specifications for this excavator:
Operating weight: 273,300 lbs (124,000 kg)
Engine: SAA6D170E-3
Max digging depth: 29'5" (9.0 m)
Max digging reach: 48'1" (14.7 m)
Max dumping height: 34'9" (10.6 m)
