OEM ENGINE AR-COMPLETE 2724687 - Caterpillar

Engine Model: Caterpillar C6.4 ACERT
Configuration: 4-stroke, inline 6-cylinder diesel engine
Displacement: 6.4 liters (389 cubic inches)
Bore and Stroke: 105 mm x 127 mm (4.13 in x 5.00 in)
Compression Ratio: 16.0:1
Max Power Output: 130 kW (174 hp) at 2,200 RPM
Max Torque: 788 Nm (581 lb-ft) at 1,400 RPM
Aspiration: Turbocharged and aftercooled
Fuel System: Common rail fuel injection
Cooling System: Liquid-cooled with heat exchanger
Lubrication System: Gear-driven oil pump with full-flow oil filter
Exhaust System: Dry-type, vertical or horizontal outlet
Emissions: Tier 3/Stage IIIA emissions compliant
Electrical System: 12-volt or 24-volt electrical system, depending on application
Weight: 730 kg (1,610 lbs) dry weight
